310S (old grade 0Cr25Ni20/ new grade 06Cr25Ni20) is an austenitic chromium-nickel stainless steel with good oxidation resistance and corrosion resistance, due to the higher percentage of chromium and nickel, 310S has much better creep strength, can continue to work at high temperatures, has good high temperature resistance.

310S Stainless steel strip Price in China ,Manufacturer of 310S Stainless Steel strip


310S stainless steel is austenitic chromium-nickel stainless steel, has good oxidation resistance, corrosion resistance, high temperature resistance, because of the higher percentage of chromium and nickel, making it has much better creep strength, can continue to work at high temperature, has good high temperature resistance.

Because of the high content of nickel (Ni), chromium (Cr), has good oxidation resistance, corrosion resistance, acid and alkali resistance, high temperature resistance, high temperature resistant steel pipe is dedicated to the manufacture of electric furnace tube and other occasions, austenitic stainless steel increases the content of carbon, due to its solid solution strengthening effect so that the strength is improved.


Standard Specification Of 310S strip

Thickness0.1mm-12mm
Width1mm-650mm
LengthSince the custom
Surface2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc
FinishHot rolled strip (HR), Cold rolled strip (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form strips, Foils, Rolls, Plain strip, Shim strip, Perforated strip, Chequered strip, Strip, Flats,
Blank (Circle), Ring (Flange) etc.


310S stainless steel composition content

GradeCMnSiPSCrMoNiN
310SMin.
Max.
≤0.08≤2.0≤1.5≤0.035≤0.0324.00-26.00/19.00-22.00



Properties of Stainless steel 310/310S
An austenitic heat resistant alloy with excellent resistance to oxidation under mildly cyclic conditions through 2000ºF. Its high chromium and nickel contents provide comparable corrosion resistance, superior resistance to oxidation and the retention of a larger fraction of room temperature strength than the common austenitic alloys like Type 304. Stainless 310 is often used at cryogenic temperatures, with excellent toughness to -450°F, and low magnetic permeability.

As you can see below, Grade 310S is a low carbon version of grade 310. 310S is less prone to embrittlement and sensitization in service.
310 UNS S31000 Chemical Composition, %

Cr

Ni

C

Si

Mn

24.0-26.0

19.2-22.0

.25 Max

1.50 Max

2.00 Max

P

S

Mo

Cu

Fe

.045 Max

.03 Max

.75 Max

.50 Max

Balance

Mechanical Properties
Representative Tensile Properties

Temperature, °F

Ultimate Tensile Strength, ksi

.2% Yield Strength, ksi

Elongation Percent

70

80

35

52

1000

67.8

20.8

47

1200

54.1

20.7

43

1400

35.1

19.3

46

1600

19.1

12.2

48

Typical Creep-Rupture Properties

Temperature, °F

Minimum Creep 0.0001%/hr, ksi

100,000 Hour Rupture Strength, ksi

12000

14.9

14.4

1400

3.3

4.5

1600

1.1

1.5

1800

0.28

0.66

1.Recommend a heat treatment system: 1030 degrees - 1180 degrees Celsius, quenching;

2.Mechanical properties including tensile strength (1.) : not less than 520; (2.) extension strength: not less than 205; (3) break elongation: not less than 35;

3.Density: 7.98

310S It is widely used in petroleum, electronics, chemical industry, medicine, textile, food machinery, building, nuclear power, aerospace, military industry and other industries.

Package Information:JQ Metal are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might otherwise be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.

  • What are your advantages?

    1) Fast delivery time.
    2) High quality, quantity is with preferential treatment.
    3) We can process to different finish you request.
    4) Main distributor and gold supplier.
    5) 800 Tons/Month, high production capability will short your wait time.
    6) Tisco, Jisco, SPSS, QPSS, Baoxin, Baosteel and other famous brand.
    7) Good quality with reasonable price.
    8) Buyer's Specification Accepted.
    9) Experienced R & D Department.
